Project Location: Inner Mongolia

Project Capacity: 476MW/476MWh

Cooperation Scope: Grid-side Power Station

Application Scenario: Combiner Cabinet

Cooperative Product: SYW6GZ-2500

Project Challenges:

Extreme high temperature of 50℃, which affects heat dissipation inside the cabinet.

Solutions:

Adopt 2P dedicated miniaturized switches to reserve more heat dissipation space.

Leverage ultra-low power consumption to address the issue of excessive system temperature rise.

Project Benefits:

The product can operate continuously at full load without derating in a high-temperature sealed environment up to 70℃, reducing system power loss.

Project Location: Inner Mongolia

Project Scale: 95MW/380MWh

Cooperation Scope: Grid-side Power Station

Application Scenario: Combiner Cabinet

Cooperative Product: SYW6GZ-1600 Combined Electrical Appliances

Project Challenge:

Difficulties in maintenance.

Solution:

Adopt frame isolation combined electrical appliances to enable convenient maintenance and easy replacement of fuses.

Project Benefits:

Reduce the full-lifecycle maintenance costs of the energy storage system.

Project Location: Chongqing

Project Capacity: 100MW/200MWh

Cooperation Scope: Grid-side Power Station

Application Scenario: Combiner Cabinet

Cooperative Product: SYW6GZ-2500

Project Challenge:

Extreme high temperature of 50℃, which affects heat dissipation inside the cabinet.

Solution:

Adopt 2P dedicated miniaturized switches to reserve more heat dissipation space.

Utilize ultra-low power consumption to address the issue of excessive system temperature rise.

Comprehensive Benefits:

The product can operate continuously at full load without derating in a high-temperature sealed environment up to 70℃, reducing system power loss.
